Brighter, Tougher, Smarter
The FOLD wall pack delivers powerful area illumination with a wide 90°×110° beam and IP65/IK08 ratings. SMD3030 LEDs, 0-10V dimming, and a 100,000-hour lifetime make it an excellent solution for car parks, security lighting, and building perimeters.
| Input Voltage | 100–277VAC | 50/60Hz |
| Power Factor | >0.95 @ 220V / >0.90 @ 100–277V |
| THD | <10 @ 220V / <20 @ 100–277V |
| Surge Protection | Internal: DM 6KV/CM 10KV, External: 10KV/20KV |
| Electrical Class | Class I |
| Working Temperature | -40°C to +50°C |
| Operating Humidity | 20–90% RH |
| Dimensions | H253 × W163 × D290 mm |
| Housing | Die-cast Aluminum |
| Mounting | Wall Mounting |
| Optics | Polycarbonate |
| Body Finish | Electrostatic Polyester Powder-Coated |
| LED Type | SMD3030 |
| Lifetime | L70B50 >100,000h | L80B20 >50,000h |
| Dimming | 0-10V / PWM / Resistor |
| Switching Cycles | >50,000 |
| Emergency Backup | Optional |
| Flicker-Free | Yes |
| Model | Power | Efficiency | System Lumen | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-FO | 120W | 130 lm/W | 15,600 lm | 90°×110° | >70 std · >80 opt |
* Values based on CCT 4000K | ±10% tolerance
