Flood Light
MASTERY
Where strength meets light: slim LED floodlight, up to 150 lm/W.
IP66
IK08
Class I
100,000 h
100-240 W
Power
13,000-36,000 lm
Lumens
130-150 lm/W
Efficiency
30° / 60° / 90°
Beam Angle
>80 / >90
CRI
100,000 h
Lifetime
Where strength meets light: slim LED floodlight, up to 150 lm/W.
Slim and powerful, this LED floodlight delivers high lumen output with wide coverage, making it perfect for outdoor lighting in tough environments. MASTERY is available at 100 W, 150 W and 240 W, with 30°, 60° and 90° beam options and innovative thermal management.
| Input Voltage | 100-277VAC · 50/60Hz |
| Power Factor | >0.95 @ 220V full load | >0.90 @ 100-277V full load |
| THD | <10 @ 220V full load | <20 @ 100-277V full load |
| Surge Protection | Internal: DM 6KV / CM 10KV · External: 10KV / 20KV |
| Electrical Class | Class I |
| Working Temperature | -20°C to +55°C |
| Operating Humidity | 10-90% RH |
| Ingress Protection | IP66 |
| Impact Rating | IK08 |
| Vibration Test | 3G |
| Housing | Die-cast aluminum |
| Mounting | Surface, pole or suspension |
| Optics | PC / Glass |
| Body Finish | Electrostatic polyester powder-coated |
| Body Color | Gray (RAL 9023) |
| LED Type | SMD3030 / SMD5050 |
| Lifetime | L70B50 > 100,000h | L80B20 > 50,000h |
| Thermal Management | Innovative thermal management |
| Dimming | Optional: 0-10V / PWM / resistor |
| Switching Cycles | >50,000 times |
| Emergency Backup | Optional |
| 100 W | H400 × W280 × D99 mm |
| 150 W | H450 × W330 × D99 mm |
| 240 W | H500 × W380 × D99 mm |
| Model | Power | Efficiency | System Lumen | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-MYP | 100W | 140 lm/W | 14,000 lm | 30° / 60° / 90° | >80 std / >90 opt |
| NLC-MYP | 150W | 150 lm/W | 22,500 lm | 30° / 60° / 90° | >80 std / >90 opt |
| NLC-MYP | 240W | 150 lm/W | 36,000 lm | 30° / 60° / 90° | >80 std / >90 opt |
| NLC-MY | 100W | 130 lm/W | 13,000 lm | 30° / 60° / 90° | >80 std / >90 opt |
| NLC-MY | 150W | 140 lm/W | 21,000 lm | 30° / 60° / 90° | >80 std / >90 opt |
| NLC-MY | 240W | 140 lm/W | 33,600 lm | 30° / 60° / 90° | >80 std / >90 opt |
* Values at CCT 4000K, ±10% tolerance. NLC-MYP uses Lumileds LEDs.
