High Bay Luminaire

NUT

High Output. Low Consumption

IP65
IK08
Colours
Ext. Service
100–277VAC
Polycarbonate
3-Year Warranty · Ext. to 5 Yrs
Up to 135 lm/W
Flicker-Free
100W
Power
13,500lm
Lumens
135 lm/W
Efficiency
150°
Beam Angle
>70
CRI
100K h
Lifetime

About this Product

The NUT high bay delivers a wide 150° beam angle for exceptional coverage with minimal fixtures. IP65/IK08 protection and a 100,000-hour lifetime ensure reliable operation in shopping malls, logistics centers, and warehouses.

Applications

The NUT is part of National Lighting Company's High Bay Luminaire range. High bay luminaires are built for tall industrial and warehouse spaces that need powerful, even downward light. Like the rest of the NLC portfolio, it is engineered and assembled in Saudi Arabia for the demands of the local environment, high ambient temperatures, dust, and a need for long, low-maintenance service life.

National Lighting Company (NLC) has manufactured lighting in the Kingdom since 1993 and is an authorized assembler for Schneider Electric. The NLC range spans street and area lighting, flood and architectural lighting, solar luminaires, and low- and medium-voltage panels, all backed by local production in Dammam, technical support, and after-sales service across Saudi Arabia.

Detailed specifications for the NUT, including wattage, lumen output, color temperature (CCT), beam angle, and ingress protection (IP) rating, are configured to each project and available on request. Contact our team for the current datasheet, pricing, and availability.

PortManufacturing WorkshopsExhibition CentersLogistics CentersIndustrial HallsCar ParksSubway / Train StationsShopping MallsWarehouses

Electrical Parameters

Input Voltage100–277VAC | 50/60Hz
Power Factor>0.95 @ 220V / >0.90 @ 100–277V
THD<10 @ 220V / <20 @ 100–277V
Surge ProtectionInternal: DM 6KV/CM 10KV, External: 10KV/20KV
Electrical ClassClass I

Environmental Parameters

Working Temperature-30°C to +45°C
Operating Humidity20–90% RH
DimensionsØ280 × H79 mm

Color Temperature Options

3000K4000K6500K

Construction

HousingDie-cast Aluminum
MountingCeiling / Pendant Mounting
OpticsPolycarbonate
Body FinishElectrostatic Polyester Powder Coating

Performance

LED TypeSMD2835
LifetimeL70B50 >100,000h | L80B20 >50,000h
Dimming0-10V / PWM / Resistor
Switching Cycles>50,000
Emergency BackupOptional
Flicker-FreeYes

Available Colors

White
Black
ModelPowerEfficiencySystem LumenBeam AngleCRI
NLC-NT100W135 lm/W13,500 lm150°>70 std · >80 opt

* Values based on CCT 4000K | ±10% tolerance
