Slim, Suspended, High-Power Lighting
The SLEEK is a slim, high-power linear high bay delivering up to 150 lm/W in a compact form. IP66 protection, hook and loop mounting, and a 100,000-hour lifetime make it ideal for industrial halls, factories, and large-area applications.
| Input Voltage | 100–277VAC | 50/60Hz |
| Power Factor | >0.95 |
| THD | <10 @ 220V / <20 @ 100–277V |
| Surge Protection | Internal: DM 6KV/CM 10KV, External: 10KV/20KV |
| Electrical Class | Class I |
| Working Temperature | -40°C to +50°C |
| Dimensions | 480D × 177H mm |
| Housing | Die-Cast Aluminum |
| Mounting | Hook and Loop Mounting |
| Optics | PC Lens and Tempered Glass |
| Body Finish | Powder-Coated |
| LED Type | SMD3030 |
| Lifetime | L70B50 >100,000h | L80B20 >50,000h |
| Dimming | 0-10V / PWM / Resistor |
| Switching Cycles | >50,000 |
| Emergency Backup | Optional |
| Flicker-Free | Yes |
| Model | Power | Efficiency | System Lumen | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-SK | 30W | 150 lm/W | 4,500 lm | 60°/90°/120° | >70 std · >80 opt |
| NLC-SK | 50W | 150 lm/W | 7,500 lm | 60°/90°/120° | >70 std · >80 opt |
| NLC-SK | 80W | 150 lm/W | 12,000 lm | 60°/90°/120° | >70 std · >80 opt |
| NLC-SK | 100W | 150 lm/W | 15,000 lm | 60°/90°/120° | >70 std · >80 opt |
| NLC-SK | 120W | 150 lm/W | 18,000 lm | 60°/90°/120° | >70 std · >80 opt |
| NLC-SK | 150W | 150 lm/W | 22,500 lm | 60°/90°/120° | >70 std · >80 opt |
* Values based on CCT 4000K | ±10% tolerance
