Contemporary Light With a Natural Soul
Built from aluminum with a powder-coated frame, OMEGA stands up to weather and corrosion without losing its finish. The wood-textured panel softens modern outdoor architecture, balancing light, form, and material.
🌳 Wood-Textured Panel
Natural wood finish panel with dual lighting modes, Cover Closed (68.5 lm/W) and Cover Open (79.6 lm/W) for flexible ambiance control.
| Input Voltage | 100–240VAC | 50/60Hz |
| Power Factor | >0.7 |
| THD | <15% |
| Surge Protection | 1KV (L-N), 2KV (L/N-PE) |
| Protection Class | Class I |
| Working Temperature | -20°C ~ +55°C |
| Operating Humidity | 10–85% RH |
| IP Rating | IP65 |
| IK Rating | IK05 |
| Dimensions | L140 × W94 × H140 mm |
| Housing | Die-Cast Aluminum |
| Mounting | Wall Mounted |
| Optics | PC |
| Body Finish | Electrostatic Polyester Powder-Coated |
| LED Type | SMD2835 |
| Lifetime | L70B50 > 30,000h |
| Dimming | Optional |
| Switching Cycles | >15,000 |
| Model | Power | Efficiency | System Lumen | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-OM | 10.5W | 68.5–79.6LM/W | 719–836LM | 82° / 90° | Standard: >80 · Optional: >90 |
* Values calculated based on CCT 3000K | ±10% tolerance
* Cover Closed: 68.5 lm/W · 719lm · 82° | Cover Open: 79.6 lm/W · 836lm · 90°
